Thrust self-aligning roller bearings can withstand high axial loads whilst also accommodating a certain amount of radial load. They possess self-aligning capabilities, enabling them to compensate for misalignment during installation. As their operating speed is limited, they are commonly used in heavy-duty applications subject to axial loads, such as rolling mills, large gearboxes, lifting machinery and heavy-duty vertical equipment.
| Bearing model number | Basic Dimensions（mm） | Basic load （KN） |
Bearing weight | |||
|---|---|---|---|---|---|---|
| d inner diameter |
D outer diameter |
B thickness |
dynamic load Cr |
static load Cor |
||
| 293/1600E | 1600 | 2280 | 408 | 36000 | 192000 | 5137 |
| 293/1250E | 1250 | 1800 | 330 | 23700 | 125000 | 2654 |
| 292/1180E | 1180 | 1520 | 206 | 10700 | 67000 | 945 |
| 292/1120E | 1120 | 1460 | 206 | 10700 | 64000 | 896 |
| 294/1060E | 1060 | 1770 | 426 | 33000 | 155000 | 4201 |
| 292/1060E | 1060 | 1400 | 206 | 10700 | 62000 | 852 |
| 294/1000E | 1000 | 1670 | 402 | 30500 | 146000 | 3575 |
| 292/1000E | 1000 | 1320 | 190 | 9600 | 55000 | 689 |
| 294/950E | 950 | 1600 | 390 | 28500 | 132000 | 3170 |
| 292/950E | 950 | 1250 | 180 | 8800 | 48500 | 577 |
| 294/900E | 900 | 1520 | 372 | 25500 | 120000 | 2744 |
| 292/900E | 900 | 1180 | 170 | 7700 | 42000 | 478 |
| 294/850E | 850 | 1440 | 354 | 24000 | 110000 | 2348 |
| 293/850E | 850 | 1250 | 243 | 12900 | 62000 | 972 |
| 292/850E | 850 | 1120 | 160 | 7100 | 40500 | 422 |
| 294/800E | 800 | 1360 | 335 | 20600 | 93000 | 1964 |
| 293/800E | 800 | 1180 | 230 | 13500 | 54000 | 824 |
| 292/800E | 800 | 1060 | 155 | 6400 | 35500 | 365 |
| 294/750E | 750 | 1280 | 315 | 19000 | 84000 | 1654 |
| 293/750E | 750 | 1120 | 224 | 12700 | 50000 | 735 |
